FEATURES
• The brand-new hydraulic pilot control technology can realize arbitrary composition of actions.
• Multiple safety protection of comprehensive video surveillance plus sound-light alarms;
• The swing mechanism is driven by an independently open hydraulic system.
• Independent hydraulic drive system and power-intensified hydraulic cooling system.
• Overall upgraded controllability, with the working speed, movement smoothness and micro-mobility perfectly integrated.
• The humanized intelligent design can fully meet the ergonomic demands.
• Mature and reliable supporting assembly configuration can achieve high cost performance.
PARAMETERS
|
Ser. No.
|
Item
|
Unit
|
Value
|
Remark
|
|
1
|
Maximum lifting weight ×radius
|
t×m
|
80×4
|
|
|
2
|
Dead weight with basic boom attached
|
t
|
72.8
|
|
|
3
|
Length of main boom
|
m
|
13~58
|
|
|
4
|
Length of fixed jib
|
m
|
6~18
|
|
|
5
|
Maximum lifting weight of fixed jib
|
t
|
7
|
|
|
6
|
Fixed jib installation angle
|
°
|
10､30
|
|
|
7
|
Max. length of main boom + fixed jib
|
m
|
49+18
|
|
|
8
|
Max.speed of single rope on the drum of main winch
|
m/min
|
125 (110, hook free falling)
|
Fourth layer of drum
|
|
9
|
Max.speed of single rope on the drum of auxiliary winch
|
m/min
|
125
|
Fourth layer of drum
|
|
10
|
Max.speed of single rope on the drum of derricking winch)
|
m/min
|
93
|
Fourth layer of drum
|
|
11
|
Swing speed
|
rpm
|
0~2
|
|
|
12
|
Travelling speed
|
km/h
|
0~1.57
|
|
|
13
|
Gradeability
|
%
|
30
|
|
|
14
|
Pressure to the ground
|
MPa
|
0.083
|
|
|
15
|
Outline dimensions length×width×height
|
m
|
13.5×3.4×3.2
|
Containing A-frame and bottom boom section
|
|
16
|
Rated power / speed
|
kW/r/min
|
199/2000
|
Weichai Power
|
|
17
|
Max. output torque / speed
|
Nm/ r/min
|
1270/1200~1500
|
|
|
18
|
Crawler gauge ×crawler length × crawler width
|
mm
|
4200×5440×800
|
Extended
|
|
2600×5440×800
|
Retracted
|
|
19
|
Environmental radiation noise during operation
|
dB
|
≤107
|
|
|
20
|
Noise in the cab during operation
|
dB
|
≤79
|
|
