FEATURES
• Excellent hoisting capacity (10%～20% higher than that of the domestic products in the same industry )
• The high-capacity hydraulic oil tank can have the hydraulic oil cooling fast and precipitated more fully to achieve better lubrication of the system.
• The high-capacity fuel tank can ensure long operation, reduce the frequency of refueling and improve the working efficiency.
• The high-power and large-torque engine can provide sufficient power.
• The steel-structure counterweight clumps features higher precision, better collision resistance and more beautiful appearance.
• The four wheels and crawler subject to special treatment feature higher bearing capacity, more sufficient reliability and more excellent durability.
• The wire rope intensity is higher than that of its peers, featuring more sufficient safety and more excellent reliability.
• The high-strength pulling plate can be installed conveniently, featuring stronger bearing capacity, more sufficient safety and more excellent reliability.
• Two tension sensors equipped can reflect the stress of the pulling plate more accurately.
PARAMETERS
|
Ser. No.
|
Item
|
Unit
|
Value
|
Remark
|
|
1
|
Maximum lifting weight ×radius
|
t×m
|
130×4.5
|
|
|
2
|
Maximum lifting moment
|
T·m
|
661.5
|
94.5 (lifting weight) × 7 (range)
|
|
3
|
Basic boom dead weight
|
t
|
113.8
|
|
|
4
|
Length of main boom
|
m
|
19~73
|
|
|
5
|
Length of fixed jib
|
m
|
13~31
|
|
|
6
|
Maximum lifting weight of fixed jib
|
t
|
13
|
|
|
7
|
Fixed jib installation angle
|
°
|
10,30
|
|
|
8
|
Maximum length of main boom + fixed jib
|
m
|
55+31,58+25,61+19
|
|
|
9
|
Speed of rope on the drum of main winch
|
m/min
|
105
|
Drum outermost layer
|
|
10
|
Speed of rope on the drum of auxiliary winch
|
m/min
|
93
|
Drum outermost layer
|
|
11
|
Speed of rope on the drum of derricking winch
|
m/min
|
52
|
Drum outermost layer
|
|
12
|
Swing speed
|
r/min
|
0~2.2
|
|
|
13
|
Travelling speed
|
km/h
|
0~1.3
|
|
|
14
|
Gradeability
|
%
|
30%
|
|
|
15
|
Pressure to the ground
|
MPa
|
0.1
|
|
|
16
|
Outline dimension length ×width ×height
|
m
|
9.55×6.5×3.2
|
Mast-free main boom
|
|
17
|
Engine rated power / speed
|
Kw/rpm
|
209/2000
|
|
|
18
|
Engine maximum output torque / speed
|
N·m/rpm
|
1424/1500
|
|
|
19
|
Engine emission standard
|
|
U. S. EPA Tier Ⅲ
|
|
|
20
|
Crawler gauge ×crawler length × crawler width
|
mm
|
5600×6850×900
|
|
