FEATURES
• The brand-new hydraulic pilot control technology can realize arbitrary composition of actions.
• Multiple safety protection of comprehensive video surveillance plus sound-light alarms;
• The swing mechanism is driven by an independently open hydraulic system.
• Independent hydraulic drive system and power-intensified hydraulic cooling system.
• Overall upgraded controllability, with the working speed, movement smoothness and micro-mobility perfectly integrated.
• The humanized intelligent design can fully meet the ergonomic demands.
• Mature and reliable supporting assembly configuration can achieve high cost performance.
PARAMETERS
|
Type
|
Ser. No.
|
Item
|
Unit
|
Value
|
|
Boom section configuration
|
1
|
Maximum lifting weight ×radius
|
t×m
|
55×3.7
|
|
2
|
Maximum lifting weight of fixed jib
|
t
|
5.5
|
|
3
|
Length of main boom
|
m
|
13～52
|
|
4
|
Length of fixed Jib
|
m
|
6～15
|
|
5
|
Longest main boom + fixed jib
|
m
|
43＋15
|
|
6
|
Luffing angle
|
°
|
30～80
|
|
7
|
Fixed jib installation angle
|
°
|
10，30
|
|
Mechanism velocity
|
8
|
Speed of rope on the drum of main winch
|
m/min
|
120/100
|
|
9
|
Speed of rope on the drum of auxiliary winch
|
m/min
|
120
|
|
10
|
Speed of rope on the drum of derricking winch
|
m/min
|
54
|
|
11
|
Swing speed
|
rpm
|
0～2.1
|
|
12
|
Travelling speed
|
km/h
|
0～1.6
|
|
|
13
|
Model
|
/
|
WP6G190E26
|
|
Engine
dynamic parameters
|
14
|
Type
|
/
|
Inline 6-cylinder intercooled turbocharged diesel engine
|
|
15
|
Rated power / speed
|
kW/rpm
|
140/1900
|
|
16
|
Maximum output torque / speed
|
Nm/rpm
|
830/1300
|
|
17
|
Displacement
|
L
|
6.23
|
|
18
|
Emission standard
|
/
|
WP6G190E26
|
|
Others
|
19
|
Gradeability
|
％
|
30
|
|
20
|
Pressure to the ground
|
MPa
|
0.069
|
|
21
|
Dead weight with basic boom attached
|
t
|
51
|
|
22
|
Total weight of complete configuration
|
t
|
57
|
|
23
|
Counterweight
|
t
|
17.5
|
|
24
|
Maximum transport weight of single part
|
t
|
32
|
|
25
|
Outline dimension length ×width ×height
|
mm
|
12800×4600(3300)×3120
|
|
26
|
Crawler gauge ×crawler length × crawler width
|
mm
|
2540×5000×760
|
|
3840×5000×760
|
