FEATURES
• The optimal design after careful consideration enables 2~2.5 MW wind power lifting to have significant advantages.
• The open-closed electro-hydraulic proportional Rexroth hydraulic system features more steady and accurate movement, higher efficiency and less energy consumption.
• Multiple safety protection of comprehensive video surveillance plus sound-light alarms;
• The nationally-patented real-time centroid detection device can instantly detect the centroid and specific pressure to ground of the complete vehicle to improve the traveling safety.
• The imported German Benz engine in agreement with Level-3 emissions features strong power, perfect matching, energy saving and environmental protection.
• The 4-wheel drive configured chassis traveling device features strong power.
• The humanized intelligent design can fully meet the ergonomic demands.
• The modularized design can facilitate product assembly and disassembly, as well as transportation and transfer.
PARAMETERS
|
Ser. No.
|
Item
|
Unit
|
Value
|
Remark
|
|
1
|
Max.lifting weight / luffing (without superlift mechanism)
|
t/m
|
450/6
|
|
|
2
|
Max.lifting weight / luffing (withsuperlift mechanism)
|
t/m
|
500/9
|
|
|
3
|
Length of heavy-duty main boom(without superlift mechanism)
|
m
|
24～84
|
|
|
4
|
Length of heavy-duty main boom(with superlift mechanism)
|
m
|
36～84
|
|
|
5
|
Length of light-duty main boom(without superlift mechanism)
|
m
|
48～102
|
|
|
6
|
Length of light-duty main boom(with superlift mechanism)
|
m
|
78～126
|
|
|
7
|
Dead weight with basic boom attached
|
t
|
370
|
|
|
8
|
Length of fixed jib (without superlift mechanism)
|
m
|
12～36
|
|
|
9
|
Max. lifting weight of fixed jib(without superlift mechanism)
|
t
|
80
|
|
|
10
|
Fixed jib installation angle(without superlift mechanism)
|
°
|
10，30
|
|
|
11
|
Main boom + fixed jib(without superlift mechanism)
|
m
|
78＋36
|
|
|
12
|
Main boom + jib used for wind power project
|
m
|
84＋12
|
|
|
13
|
Max. lifting weight of jib used for wind power project
|
t
|
110
|
|
|
14
|
Installation angle of jib used for wind power project
|
°
|
15
|
|
|
15
|
Length of luffing jib
|
m
|
24～84
|
|
|
16
|
Max. lifting weight of luffing jib (without superlift mechanism)
|
t
|
142
|
|
|
17
|
Max. lifting weight of luffing jib (with superlift mechanism)
|
t
|
225
|
|
|
18
|
Working angle of main boom under working condition with luffing jib
|
°
|
65、75、85
|
|
|
19
|
Speed of single rope on the drum of main winch
|
m/min
|
0～143
|
|
|
20
|
Speed of single rope on the drum of auxiliary winch
|
m/min
|
0～143
|
|
|
21
|
Speed of single rope on the drum of derricking winch
|
m/min
|
0～2×50
|
|
|
22
|
Speed of single rope on the drum of tower jib derricking winch
|
m/min
|
0～122
|
|
|
23
|
Speed of single rope on the drum of superlift derricking winch
|
m/min
|
0～143
|
|
|
24
|
Speed of single rope on the drum of tip boom hoisting winch
|
m/min
|
0～108
|
|
|
25
|
Swing spee
|
|
|
|
